Model

Aries 213

Aries 124


Max Print Width

30cm (11.81″)

60cm (23.6″)

Printing Speed

12Pass, 720x1800dpi, 0.74㎡/h (7.97ft²/h);

8Pass, 720*1200dpi, 5.5m²/h (59.2ft²/h)

Net Weight (kg)

126.5 kg / 278.9 lb

327 kg (720.6 lb)

Main Board & Print Head

DTF STATION PILOT/EPSON I3200HD-U1

DTF STATION PILOT/Epson i1600*4

Daily Output
Based on 7.5″x4″ gangsheet, 8 working hours

270pcs (720*1800dpi)

1352pcs (720*1200dpi)

Size

Printer Size
119.7cm × 90.5cm × 112.2cm
(47.1″W×35.6″D×44.2″H)

Packing Size
111cm × 106cm × 72cm
(43.7″W × 41.7″D × 28.3″H)

Printer Size
225.6cm × 109.5cm × 159.7cm
(88.8″W × 43.1″D × 62.9″H)

Packing Size
265cm × 114cm × 84.6cm
(104.3″W × 44.9″D × 33.3″H)

Prisma Duet Hat Press Machine: Elevate Your Brand with Impeccable Hat Press and Logo Printing

The game-changing heat press machine designed to take your brand to new heights.
Combining unrivaled performance and effortless operation for professional-grade results.

Overview

Specification

Downloads

The Prisma Duet Heat hat press machine is specially developed for logo printing. No matter what substrate you're pressing on, whether it's a curved or straight surface, the Prisma Duet will get the job done easily and reliably.

Key Features

2-in-1 Logo and Cap Press
Digital Control Panel
Easy to Operate and install
Friendly for beginners
Compact in size and lightweight

Benefit

One press to do all the logo printing jobs that you expected!

Compatiable With

All the Prestige Series Printer, shaker and oven.

Model Name	Prisma Duet Heat Press
Power Requirements (Flat)	700W, 120V;6.4A / 240V;3.2A
Power Requirements (Cap)	500W, 120V;4.5A / 240V;2.3A
Heater Size (Flat)	18"x10"
Heater Size (Flat)	2.75"x6.5" / 3.5"x6.5" / 3"x5.75" / 4"x6.5" / 4"x8"
Temperature Range	Max.221℃/430°F
Heating Up Time	15 minutes
Product Weight	29.2kg
Packaging Weight	31.2kg
Machine Dimensions	567x246x550mm (While Open)
Packaging Dimensions	548x462x512mm
Certificate:	CE,FCC
Warranty	One year warranty on the entire machine, 3 years warranty on the heat platen
Suitable Users	All DTF sheet printing users

Oops! Looks like we haven't filled this tab with anything yet - it's as empty as a blank t-shirt waiting to be printed! But don't worry, we're working on it and will soon be adding some awesome files that will make your DTF printing experience even better. Stay tuned and keep checking back!

Videos To Maximize Prisma Duet's Potential

Playlist

1 Videos

0:16

What Can You Print With Hat Press Machine?

FAQs

Can I print different size of cap with the press machine?

Yes, we have several sizes of cap platens available.

What‘s the operation mode of this machine?

Prisma Duet only supports manual operation modes,but it works for both cap and logo printing.

Pick the Right Heat Press Machine for Your Business

Model	Prisma Swing	Prisma Auto	Prisma Palette	Prisma Hobby	Prisma Duet
Price Range
Recommended Use	Premium Production Use	Premium Production Use	Advanced Hobby & Home Use	Hobby & Home Use	Advanced Hobby & Home Use
Durability
User Friendly
Available Sizes	16″x20″	16″x20″, 15″X15″	13.8″x16.5″	8.3″x11.8″	Rechangeable platen with different sizes
Auto-open/Manual	Manual	Optional	Optional	Manual	Manual
Format	Swing Away	Clamshell; Manual&Auto-Open Interchangeable; Slider-Out	Clamshell	Clamshell	Clamshell
Ramlock System	YES	YES	YES	NO	Yes
Pressure Read Out	NO	YES	NO	NO	N/A
Nonstick Coating	Sprayed On	Sprayed On	Sprayed On	Sprayed On	Sprayed On
Temperature& Time Gauge	Digital Automatic Start	Digital Automatic Start	Digital Automatic Start	Digital Automatic Start	Digital Automatic Start
Weight(kg)	16″x20″ 42KG	15″x15″-49KG; 16″x20″-54KG	30KG	15KG
Suitable for	Dye-sub Laser Transfer Vinyl Transfer Screen Printed Transfer	Dye-sub Laser Transfer Vinyl Transfer Screen Printed Transfer	Dye-sub Vinyl Transfer Screen Printed Transfer	Dye-sub Vinyl Transfer Screen Printed Transfer	Cap & LOGO Decorators T-shirts, Jackets, legs,etc All types of LOGO decoration.
Warranty	10 years on heat platen 1 year on parts	10 years on heat platen 1 year on parts	5 years on heat platen 1 year on parts	3 years on heat platen 1 year on parts	1 year on whole machine
