Prisma Hobby Small Heat Press: Your Portable Partner in Creativity!

Perfect blend of lightweight design and powerful functionality
Designed for dye-sub starters, vinyl crafters, and laser transfers,

Overview

Specification

Downloads

Prisma Hobby Clamshell A4 Small Heat Pess

Prisma Hobby Heat Press is an A4 size press, suitable for dye-sub starter, vinyl crafter, all types of transfer printing. So it is a perfect press for hobby or starter or if you are struggling with space at your shop or working places.

15kg weight including packing can let you be managed to take with you where ever you want, so if you are running a business for party or small events to local market, the Prisma Hobby should be your choice!

Elegant design with inter changeable control box brings after sales service to next level!
Three colors for your options: Classic Black & Grey, Pink, Mint.

Key Features

LED Digital Display
Interchangeable Control Box
Heat Platen: Superior evenness heating
Compact Design
Over The Center Pressure Distribution
Gas-springs Lift
Dressable Lower Platen

Benefits

Easy to operate and maintenance!
Economical but presenting like a robot.

Compatiable with

All the Prestige Series Printer ,shaker and oven

Model Name	Prisma Hobby
Heater Size	8.3"X11.8" (210X300mm)
Lower Platen Size	8.5"X12.1" (216X308mm)
Power Requirements	700W, 120V;6A / 240V;3.5A
Temperature Range	Max.221℃/430°F
Heating Up Time	180℃/15 mins
Time Range	0~999S
Auto-open/Manual	Manual
Pressure Display	NO
Product Weight	13.6kg
Packaging Weight	15.5kg
Machine Dimensions	430x310x371mm
Packaging Dimensions	500x370x420mm
Certificate	FCC; CE
Warranty	One year warranty on the entire machine, 3 years warranty on the heat platen

Oops! Looks like we haven't filled this tab with anything yet - it's as empty as a blank t-shirt waiting to be printed! But don't worry, we're working on it and will soon be adding some awesome files that will make your DTF printing experience even better. Stay tuned and keep checking back!

Videos To Maximize Prisma Hobby's Potential

Playlist

1 Videos

0:16

What Can You Print With Prisma Hobby A4 Mini Heat Press?

FAQs

What‘s the operation mode of this machine?

Prisma Hobby supports one operation modes, manual.

Can I change the lower lower platen into other sizes?

No, Prisma Hobby only have one size in lower platen: 21.6*30.8cm.

Pick the Right Printers for Your Business

Model	Prisma Swing	Prisma Auto	Prisma Palette	Prisma Hobby	Prisma Duet
Price Range
Recommended Use	Premium Production Use	Premium Production Use	Advanced Hobby & Home Use	Hobby & Home Use	Advanced Hobby & Home Use
Durability
User Friendly
Available Sizes	16″x20″	16″x20″, 15″X15″	13.8″x16.5″	8.3″x11.8″	Rechangeable platen with different sizes
Auto-open/Manual	Manual	Optional	Optional	Manual	Manual
Format	Swing Away	Clamshell; Manual&Auto-Open Interchangeable; Slider-Out	Clamshell	Clamshell	Clamshell
Ramlock System	YES	YES	YES	NO	Yes
Pressure Read Out	NO	YES	NO	NO	N/A
Nonstick Coating	Sprayed On	Sprayed On	Sprayed On	Sprayed On	Sprayed On
Temperature& Time Gauge	Digital Automatic Start	Digital Automatic Start	Digital Automatic Start	Digital Automatic Start	Digital Automatic Start
Weight(kg)	16″x20″ 42KG	15″x15″-49KG; 16″x20″-54KG	30KG	15KG
Suitable for	Dye-sub Laser Transfer Vinyl Transfer Screen Printed Transfer	Dye-sub Laser Transfer Vinyl Transfer Screen Printed Transfer	Dye-sub Vinyl Transfer Screen Printed Transfer	Dye-sub Vinyl Transfer Screen Printed Transfer	Cap & LOGO Decorators T-shirts, Jackets, legs,etc All types of LOGO decoration.
Warranty	10 years on heat platen 1 year on parts	10 years on heat platen 1 year on parts	5 years on heat platen 1 year on parts	3 years on heat platen 1 year on parts	1 year on whole machine
